RUDE DOG - Steelers
|
 |
« on: January 24, 2010, 08:49:35 PM » |
|
|
|
|
|
« Last Edit: January 25, 2010, 12:05:15 PM by STEELERS »
|
Logged
|
|
|
|
houstone
Member
Posts: 377
Can't get enough...
Santa Fe, TX
|
 |
« Reply #1 on: January 24, 2010, 09:02:17 PM » |
|
Very nice!  |
|
|
|
|
Logged
|
|
|
|
Colin
Member
Posts: 597
My old job
Orba, Spain
|
|
« Reply #2 on: January 24, 2010, 11:53:39 PM » |
|
Very nice. Any tricks or just loads of hard work with fine paper and polishing mops? |
|
|
|
|
Logged
|
|
|
|
|
BamaDrifter64
|
|
« Reply #3 on: January 25, 2010, 12:39:57 AM » |
|
Nice outcome....how many hours did you put into them?  Dave |
|
|
|
|
Logged
|
|
|
|
|
Chrisj CMA
|
|
« Reply #4 on: January 25, 2010, 05:21:24 AM » |
|
Are you actually going to put them back on the bike and kill bugs with them.........they look too nice for that....LOL Just kidding of course.....I wish I had the patience, they look very cool!!!
|
|
|
|
|
Logged
|
|
|
|
Disco
Member
Posts: 4899
Armed Man=Citizen; Unarmed Man=Subject
Republic of Texas
|
|
« Reply #5 on: January 25, 2010, 05:23:35 AM » |
|
Beautiful! Dangit, my to-do list just got longer... |
|
|
|
|
Logged
|
2000 Bumblebee "Tourer", 98 Yellow & Cream Tourer, 97 Rescue blower bike 22 CRF450RL, 19 BMW R1250RT 78 CB550K 71 Suzuki MT50 Trailhopper .jpg) VRCC 27,916 IBA 44,783 |
|
|
|
rangernight
|
|
« Reply #6 on: January 25, 2010, 07:28:10 AM » |
|
1st class work, very nice!!!!!!! Wish I had the patience!!!!
|
|
|
|
|
Logged
|
|
|
|
MP
Member
Posts: 5532
1997 Std Valkyrie and 2001 red/blk I/S w/sidecar
North Dakota
|
|
« Reply #7 on: January 25, 2010, 07:43:26 AM » |
|
Procedure?
MP
|
|
|
|
|
Logged
|
 "Ridin' with Cycho" |
|
|
|
RUDE DOG - Steelers
|
|
« Reply #8 on: January 25, 2010, 08:58:04 AM » |
|
I did tons of reading first but since I was dealing with Daryl on ordering my raked trees, I decided to take his advice on polishing the forks which was less time consuming compared to many others. I bought a small orbital hand sander ($25) and a bench mounted buffing wheel ($40) which were the biggest expenses at Harbor Freight. A lot of people start with say 200 grit paper and go up in increments of 200 all the way to 1000 or even 2000 grit and then start using Tripoli and polishing sticks. Daryls suggestions were this which I followed exactly.
Fork Lowers:
Acetone or Oven Cleaner to remove clear coat
Orbital Hand sander with 320 grit wet sand paper
Buffing wheel with Tripoli
Buffing wheel with White Polishing Compound
Uppers:
Acetone or Oven Cleaner to remove clear coat
Orbital Hand sander with 320 grit wet sand paper
Orbital Hand sander with 400 grit wet sand paper
Buffing wheel with Tripoli
Buffing wheel with White Polishing Compound
I have to say the lowers were much more time consuming than the uppers. I did a good amount of the sanding of the lowers by hand because of all the small curves. I also used a dremel in the small places to polish them. When sanding the uppers, he suggests to not polish the areas where the trees mount as there is no need to make that area smooth or slippery. I dont know how many hours I spent but it wasnt as bad as I thought it would be. Once I got the lowers done, the rest went fairly quick. When removing the clear coat I used the Acetone on the lowers and then tried the Oven cleaner for the uppers. I did my best to get most of the clear off but since I was going to be sanding the hell out of the forks, that was going to take off most of it anyway. On the uppers, make sure you sand away all the ribbed tool marks to get the smooth finish. Once I did the bulk of the sanding on the lowers, I would just sit and watch TV hand sanding all the small areas. For the Uppers, I hand sanded the areas where the line was for where the treees mount first and then went to town with the orbital. Good luck. Its worth the time spent. If not for Daryls help, I would still be working on them.
|
|
|
|
|
Logged
|
|
|
|
|
sandy
|
|
« Reply #9 on: January 25, 2010, 10:02:09 AM » |
|
Before you install them, take them to a powdercoater. Get them clear powdercoated. Never have to polish again.
|
|
|
|
|
Logged
|
|
|
|
Relax
Member
Posts: 322
Power & elegance...just like the Valk
Oslo, Norway
|
|
« Reply #10 on: January 25, 2010, 10:08:53 AM » |
|
unbelieveable result!!! Really good looking!
|
|
|
|
|
Logged
|
|
|
|
Joe Hummer
Member
Posts: 1645
VRCC #25677 VRCC Missouri State Representative
Arnold, MO
|
|
« Reply #11 on: January 25, 2010, 10:13:07 AM » |
|
So...you can send me your shocks and I will send you mine and you can start all over. Let me know when you need my mailing address.  Joe |
|
|
|
|
Logged
|
1999 Valkyrie Interstate
You pay for the whole bike, why not use it Jerry Motorman Palladino
|
|
|
gordonv
Member
Posts: 5763
VRCC # 31419
Richmond BC
|
|
« Reply #12 on: January 25, 2010, 12:19:48 PM » |
|
Before you install them, take them to a powdercoater. Get them clear powdercoated. Never have to polish again.
They have clear coat for powder coating? Didn't know that, was just going to us a spray bomb and clear coat it myself. I think the powder coat would be better in the long run, and worth the extra cost. |
|
|
|
|
Logged
|
1999 Black with custom paint IS   |
|
|
|
RUDE DOG - Steelers
|
|
« Reply #13 on: January 25, 2010, 12:21:58 PM » |
|
So...you can send me your shocks and I will send you mine and you can start all over. Let me know when you need my mailing address. Joe Thanks for the offer Joe, but that was enough practice for me.  |
|
|
|
|
Logged
|
|
|
|
Black Dog
Member
Posts: 2606
VRCC # 7111
Merton Wisconsin 53029
|
|
« Reply #14 on: January 25, 2010, 12:56:16 PM » |
|
Hey Steelers... Those look beautiful Did you need to disassemble the forks, or did you leave them, and work on each one as a whole assembly? Black Dog |
|
|
|
|
Logged
|
Just when the highway straightened out for a mile And I was thinkin' I'd just cruise for a while A fork in the road brought a new episode Don't you know... Conform, go crazy, or ride a motorcycle...  |
|
|
Smokinjoe-VRCCDS#0005
Member
Posts: 13834
American by Birth, Southern by the Grace of God.
Beautiful east Tennessee ( GOD'S Country )
|
|
« Reply #15 on: January 25, 2010, 02:49:16 PM » |
|
Hey Steelers... Those look beautiful Did you need to disassemble the forks, or did you leave them, and work on each one as a whole assembly? Black Dog Looks great ...Well done |
|
|
|
|
Logged
|
 I've seen alot of people that thought they were cool , but then again Lord I've seen alot of fools. |
|
|
|
RUDE DOG - Steelers
|
|
« Reply #16 on: January 25, 2010, 03:00:56 PM » |
|
Hey Steelers... Those look beautiful Did you need to disassemble the forks, or did you leave them, and work on each one as a whole assembly? Black Dog I did not disassemble the forks though if you did it may be easier to work on the lowers. Wasnt too bad though. |
|
|
|
|
Logged
|
|
|
|
|
Don07tncav
|
|
« Reply #17 on: January 25, 2010, 03:07:35 PM » |
|
WOW! Look fantastic!
|
|
|
|
|
Logged
|
Keep two up!  |
|
|
|
Larry
|
|
« Reply #18 on: January 25, 2010, 03:38:18 PM » |
|
Have you done the rims already?  |
|
|
|
|
Logged
|
To Ride or Not To Ride? RIDE of course!!!
|
|
|
RTaz
Member
Posts: 1319
Michigan...Home of InZane X -XI
Oscoda, Michigan
|
|
« Reply #19 on: January 25, 2010, 03:45:06 PM » |
|
 Had a local guy polish these a few years ago.... |
|
|
|
|
Logged
|
 RTaz |
|
|
GJS
Member
Posts: 424
Today is the tomorrow you worried about yesterday.
Vancouver Island, BC, Canada
|
|
« Reply #20 on: January 25, 2010, 06:02:42 PM » |
|
Those look awesome!
I too have just taken delivery of a 6degree triple tree set from Daryl.
Very helpful fellow indeed.
Now that I have seen yours, I'll need to polish the mine like that, for sure.
I guess the good news is I have an Interstate and won't need to do all of the uppers, although once I start....
So are you extending the length of your forks? Daryl sent me 1 3/8" extensions.
I'm 5'10" with a 30" inseam.
He also mentioned that I would not have to shorten my kickstand with the extensions.
Has anyone here ever shortened their kickstand?
Best regards,
Glenn
|
|
|
|
|
Logged
|
The tragedy of life is not that it ends so soon, but that we wait so long to begin it.
- W. M. Lewis
|
|
|
Smokinjoe-VRCCDS#0005
Member
Posts: 13834
American by Birth, Southern by the Grace of God.
Beautiful east Tennessee ( GOD'S Country )
|
|
« Reply #21 on: January 25, 2010, 06:28:00 PM » |
|
Had a local guy polish these a few years ago.... One of the sharpest Valkyrie's I've ever saw ... Beautiful Bike |
|
|
|
|
Logged
|
I've seen alot of people that thought they were cool , but then again Lord I've seen alot of fools. |
|
|
|
RUDE DOG - Steelers
|
|
« Reply #22 on: January 25, 2010, 07:04:56 PM » |
|
Had a local guy polish these a few years ago.... |
|
|
|
|
Logged
|
|
|
|
|
RUDE DOG - Steelers
|
|
« Reply #23 on: January 25, 2010, 07:09:19 PM » |
|
Those look awesome!
I too have just taken delivery of a 6degree triple tree set from Daryl.
Very helpful fellow indeed.
Now that I have seen yours, I'll need to polish the mine like that, for sure.
I guess the good news is I have an Interstate and won't need to do all of the uppers, although once I start....
So are you extending the length of your forks? Daryl sent me 1 3/8" extensions.
I'm 5'10" with a 30" inseam.
He also mentioned that I would not have to shorten my kickstand with the extensions.
Has anyone here ever shortened their kickstand?
Best regards,
Glenn
Hey Glenn, I should have my trees by the end of this week. Im not using the extensions. I have 11.5 inch Progressives so the 6 degree trees will make bring it down to where it should be. Let me know how your install goes. Ive never installed triple trees before so I'll take all the suggestions I can get. |
|
|
|
|
Logged
|
|
|
|
mirion
Member
Posts: 254
1997 Std - 2000 IS
Frankenmuth, Michigan
|
|
« Reply #24 on: January 25, 2010, 07:10:22 PM » |
|
Hey Steelers, did you do the lowers with the tubes on or did you take them apart? Now I am convinced I have to do them also although I already bought some of the Hondaline chrome "Lower Fork Covers" because I didn't think you get them that nice. Daryl is having a good month, my 6 degree trees are due this week. Just got done polishing my tubes also. I had the good fortune of a metal lathe at my disposal so I started with 280 which took off the clear coat and the lathe grooves pretty fast. Then switched to 400 to 600 to 1000 and finished with a spiral sewn wheel in my 6" hand grinder and red compound while still on the lathe. I bought a complete polishing kit from http://www.caswellplating.com/buffs/gbkit.html . Now I am starting on the wheels.  |
|
|
|
|
Logged
|
|
|
|
|
RUDE DOG - Steelers
|
|
« Reply #25 on: January 25, 2010, 07:16:30 PM » |
|
Your uppers look great. My tubes were all together. I did not take anything apart. Lowers are just more time consuming. I did alot of hand sanding to get most of the areas a pretty smooth finish. Let me know how your install goes also.
|
|
|
|
« Last Edit: January 25, 2010, 07:18:01 PM by STEELERS »
|
Logged
|
|
|
|
mirion
Member
Posts: 254
1997 Std - 2000 IS
Frankenmuth, Michigan
|
|
« Reply #26 on: January 25, 2010, 07:45:06 PM » |
|
I also have the 11.5 Progressives and am not using any fork extensions per my discussions with Daryl. All in all it still reduces the trail from 6.0" stock to 3.75" which I hope isn't detrimental to handling. Yes Steeler and Floppy Doctor, lets compare notes on the reassembly of the new trees although I am doing a lot of things and won't be putting the forks back on for a couple weeks probably, especially with all the polishing I want to do. I really have her torn down.......  |
|
|
|
|
Logged
|
|
|
|
RTaz
Member
Posts: 1319
Michigan...Home of InZane X -XI
Oscoda, Michigan
|
|
« Reply #27 on: January 25, 2010, 07:46:26 PM » |
|
Had a local guy polish these a few years ago.... that was a project bike that my buddy Joe Errante (Joes Juice guy) asked me to help him out with...we did a frame up rebuild on it and pretty much re-did the whole thing in my garage...great bike...he sold it a few years ago...  |
|
|
|
« Last Edit: January 25, 2010, 07:50:52 PM by RTaz »
|
Logged
|
RTaz |
|
|
HotRod
Member
Posts: 909
2001 I/S First one was a 1999 I/S
Henderson, NV
|
|
« Reply #28 on: January 26, 2010, 11:04:50 AM » |
|
At first I looked at your first pictures and did not see the BEFOR heading and thought thats not that great. Then I woke up and seen the after and WOW! great work man! that looks like something I would love to do to mine.
|
|
|
|
|
Logged
|
|
|
|
|
|
|
Kelm1
|
|
« Reply #30 on: January 26, 2010, 08:14:10 PM » |
|
After seeing STEELERS forks I'm going to have to try it. I plan on pulling the forks off soon to upgrade to progressive springs along with new seals and oil. Perfect timing! I hope they turn out as good. I like the idea of clear coating. Will a good auto grade clear do the job?
|
|
|
|
|
Logged
|
|
|
|
|
garyr
|
|
« Reply #31 on: January 27, 2010, 12:44:24 PM » |
|
Great job and time consuming.
I had my triple trees chromed and my forks polished. I had them clear coated and 3 years later the clear is dulling and they are chipped. Clear powder coat is the way to go but you have to take the forks apart. I have 2 other bikes with polished forks with no coating and I have to polish them at least twice a year.......
|
|
|
|
« Last Edit: January 27, 2010, 12:46:43 PM by garyr »
|
Logged
|
Currently Own
78 Street Tracker
79 XS 650 Standard
72 Yamaha DT2 250
74 Kaw 2 stroke S3 400 triple
74 Suzuki GT 750
06 Triumph Speed Triple
02 Honda Valkyrie-6cyl
09 KLR 650
|
|
|
PINSTRIPERART
Member
Posts: 37
I ride a 2000 valk tourer
san antonio
|
|
« Reply #32 on: February 05, 2013, 06:42:10 AM » |
|
I have found the best thing to use is jewelers roug. At most truck stops you will find tank and wheel polishers who will be glad to sell you a bottle of their home made magic polish, this usually works the best
|
|
|
|
|
Logged
|
|
|
|
|
olddog1946
|
|
« Reply #33 on: February 05, 2013, 12:19:47 PM » |
|
Those look incredibly nice....BUT way too much work for a lazy fart like me, lol. I did that once with the side cases on a Suzuki GT 380, looked real nice for awhile but unless you have some kind of clear coat on them, and you are picky you'll be spending a lot of time keeping them looking that nice.. I'd rather ride with that time, but I do like the look.
|
|
|
|
|
Logged
|
VRCC # 32473
US AIR FORCE E7, Retired 1965-1988
01 Valk Std.
02 BMW k1200LTE
65 Chevelle coupe, 1986 Mazda RX-7 with 350/5spd, 1983 Mazda RX-7 with FOMOCO 302/AOD project, 95 Mustang GT Convertible 5.0, 5 spd
Moses Lake, Wa. 509-760-6382 if you need help
|
|
|
|
Jack B
|
|
« Reply #34 on: February 05, 2013, 04:05:53 PM » |
|
Yea it takes time but it's worth it   |
|
|
|
|
Logged
|
Let’s RIDE
|
|
|
|
