Author Topic: Bike work platform done, starting '99 Valk job.  (Read 2176 times)
Tropic traveler
Member
*****
Posts: 3117


Livin' the Valk, er, F6B life in Central Florida.

Silver Springs, Florida
« on: July 09, 2011, 05:35:18 PM »
Finally got time to finish my homemade motorcycle work platform. Finished it this morning & immediately started the teardown of my '99.
4' x 8' made of 2x12's & 8' 4x4 posts. Ran 2x4 stringers underneath & 6 eye bolts for tiedown points. Welded up some 2x4 box tubing on 1/8" steel for the tire squeezer. Used 3/4 all thread for the squeezer. After performing the rear service on my '97 with a floor jack & sweating every second of it I vowed next time I would have a suitable SAFE & STURDY way to work. Copied some bike table tire clamp set ups I had seen online & in person & added some extra beef.





Did not want a lift table, I can still get up & down pretty well & it had to be wide enough to park a bike on when not in use. Mission accomplished!
I can detach the LH squeezer part to make more room if needed.
Anyways, needing new tires & I wanted to get a look at the condition of the rear splines as well. Bike has 49K & I did not know it's history. Turns out everything was in good shape, the p.o. treated her well!  cooldude
Car tire going bye-bye!


But first I wanted to pull the baffles out of the Cobras to wrap them up to make them quieter. Made a Redneck baffle puller out of an old screwdriver but still had to get nasty with the welder on one baffle!


Contrast how secure the '99 looks on the platform with the jackstands & steel bar holding it up compared to how my '97 looked last year doing the same job!




Busy day, got a lot done!  Cool
Logged
'13 F6B black-the real new Valkyrie Tourer
'13 F6B red for Kim
'97 Valkyrie Tourer r&w, OLDFRT's ride now!
'98 Valkyrie Tourer burgundy & cream traded for Kim's F6B
'05 SS 750 traded for Kim's F6B
'99 Valkyrie black & silver Tourer, traded in on my F6B
'05 Triumph R3 gone but not forgotten!
Smokinjoe-VRCCDS#0005
Member
*****
Posts: 13836


American by Birth, Southern by the Grace of God.

Beautiful east Tennessee ( GOD'S Country )
« Reply #1 on: July 09, 2011, 06:22:35 PM »
I kinda have the same set-up I will say mine has alittle more redneck engineering  Smiley   Well done  cooldude  Mine works great and I use it all the time in fact I've got a bike parked on it now .I've never took a picture of it however I did find this one.I've got a much better jack now than the one in the picture.
Logged


I've seen alot of people that thought they were cool , but then again Lord I've seen alot of fools.
eric in md
Member
*****
Posts: 2495


ride hard now we all can rest when were gone !!!

in the mountains .......cumberland md
« Reply #2 on: July 09, 2011, 07:46:54 PM »
sorry joe .. every time i see your baby girl its put a smile on my face what a cutiepie ... cooldude
Logged
Tropic traveler
Member
*****
Posts: 3117


Livin' the Valk, er, F6B life in Central Florida.

Silver Springs, Florida
« Reply #3 on: July 09, 2011, 08:55:14 PM »
Thank ya, Joe!
Next project is a homemade tire changer so I never have to wait for a shop to put on a new tire. With all the damn flats I seem to have I think it will be a good move.  cooldude
Logged
'13 F6B black-the real new Valkyrie Tourer
'13 F6B red for Kim
'97 Valkyrie Tourer r&w, OLDFRT's ride now!
'98 Valkyrie Tourer burgundy & cream traded for Kim's F6B
'05 SS 750 traded for Kim's F6B
'99 Valkyrie black & silver Tourer, traded in on my F6B
'05 Triumph R3 gone but not forgotten!
RoadKill
Member
*****
Posts: 2591


Manhattan KS
« Reply #4 on: July 09, 2011, 09:44:26 PM »
Quote from: Tropic traveler on July 09, 2011, 08:55:14 PM
Thank ya, Joe!
Next project is a homemade tire changer so I never have to wait for a shop to put on a new tire. With all the damn flats I seem to have I think it will be a good move.  cooldude



I'm right there with ya on that idea. Are you gonna make it MC only ?  I do more trailer and tractor tires than bike. I'm going for a design for any and all tires.
Logged
Tundra
Member
*****
Posts: 3882


2014 Valkyrie 1800

Seminole, Florida
« Reply #5 on: July 10, 2011, 04:48:09 AM »
Way to go Eddie cooldude You've got three Valks, you need a place to work on them. That looks like a great alternative, actually looks like the MOST STABLE I've ever seen.
  I was looking at lift table a while back when I had a decent income and couldn't pull the trigger. Waaay too much money for me, I'll get on the floor, or on my roll around. Smiley
Logged
If you can't be a good example: be a WARNING!!
Thunderbolt
Member
*****
Posts: 3726


Worthington Springs FL.
« Reply #6 on: July 10, 2011, 07:59:01 AM »
I've got an old buzz box welder, but never took shop or learned how to weld nice beads like you can.  Mostly mine are ugly and sometimes they work for a while, if I want better looking welds I call my son.
Logged
3fan4life
Member
*****
Posts: 6986


Any day that you ride is a good day!

Moneta, VA
« Reply #7 on: July 10, 2011, 09:05:05 AM »
Quote from: Tropic traveler on July 09, 2011, 08:55:14 PM



Hey that spot looks Kinda familiar:
Logged
1 Corinthians 1:18
Thunderbolt
Member
*****
Posts: 3726


Worthington Springs FL.
« Reply #8 on: July 10, 2011, 11:49:17 AM »
If it was winter he would have had his COLD weather gear on.  Grin
