Bad On 3
Member
Posts: 103
RIDIN THE BEAST ! !
CHICAGO IL. 60638
|
 |
« on: January 09, 2012, 06:38:04 AM » |
|
Hi i have alot of air comming from bottom of fairing and the gas tank on a 99 interstate --hits me in the chest --not too bad when its hot but when its alittle cooler i would like to stop some of it --i dont know about the air wings that go on the forks and dont want to spend alot of money if they dont work --any input would be great --Thanks and Ride Safe !!!!!
|
|
|
|
|
Logged
|
Ridin Down The Road Of Life With My Friends !! What a Ride !!
|
|
|
fudgie
Member
Posts: 10614
Better to be judged by 12, then carried by 6.
Huntington Indiana
|
|
« Reply #1 on: January 09, 2012, 07:01:23 AM » |
|
Do you have the wings on bottom of the fairing? I had the same thing when I put a b'wing on. Did the fork wings with little effect. Once I put the wings under the fairing, it took it all away.
|
|
|
|
|
Logged
|
 Now you're in the world of the wolves... And we welcome all you sheep... VRCC-#7196 VRCCDS-#0175 DTR PGR |
|
|
|
Ricky-D
|
|
« Reply #2 on: January 09, 2012, 07:02:10 AM » |
|
Are you sure that's where it is coming from?
Holding you thighs closer to the tank will stop most of that air, I find.
Very little coming over the tank.
Do you still have the small clear plastic "lowers" on the fairing?
***
|
|
|
|
|
Logged
|
2000_Valkyrie_Interstate
|
|
|
Bad On 3
Member
Posts: 103
RIDIN THE BEAST ! !
CHICAGO IL. 60638
|
|
« Reply #3 on: January 09, 2012, 07:15:26 AM » |
|
Hi thanks i have the baker airwings on the fairing by the pods that helps with the air hiting the passenger -I had to remove the little air deflectors on the bottom of fairing they would have hit the new ones -i think i need the air deflectors that mount on the forks but dont know if they are worth the money --the air seems to be strong comming between the fairing and fuel tank --tryed some fome inserts from a 1500 wing and it cuts down on the air comming thru but looks like crap and they move around --goes around the handlebars between the fairing and the tank --THANKS
|
|
|
|
« Last Edit: January 09, 2012, 07:18:10 AM by Bad On 3 »
|
Logged
|
Ridin Down The Road Of Life With My Friends !! What a Ride !!
|
|
|
|
Cliff
|
|
« Reply #4 on: January 09, 2012, 08:06:41 AM » |
|
On my 2000 I/S with bakers I added the fork deflectors and now riding in cold weather is much better (18 degrees is the coldest I've ridden in and no heated gear) ,, far less air coming up into my chest area. Glad I added them. For summer I leave them on and adjust the bakers to direct more air inward if needed.
|
|
|
|
|
Logged
|
VRCC # 29680
|
|
|
Willow
Administrator
Member
Posts: 16679
Excessive comfort breeds weakness. PttP
Olathe, KS
|
|
« Reply #5 on: January 09, 2012, 10:57:06 AM » |
|
... -I had to remove the little air deflectors on the bottom of fairing they would have hit the new ones -i think i need the air deflectors that mount on the forks You've robbed Peter to pay Paul and you're wondering why Peter is poor.
To do a thorough job you'll need the deflectors both on the bottom of the fairing and on the forks.
Or you can simply learn to enjoy the wind knowing your passenger is comfy.  |
|
|
|
|
Logged
|
|
|
|
fudgie
Member
Posts: 10614
Better to be judged by 12, then carried by 6.
Huntington Indiana
|
|
« Reply #6 on: January 09, 2012, 12:39:10 PM » |
|
willow the word master is right.  You removed your lowers to add the bakers so you lost one but gained another. To me, my lowers were a waste of money. Even tho I got them for $50. Mine did no good on the tank wind, which is why I bought them. They are alot bigger then you normally see. Instead they help keep my hat from buffeting on my head. I do use them to travel as they are a good bug collector. The wing lowers took all my tank/chest wind away. Maybe switch for a day and see what you like better. |
|
|
|
|
Logged
|
Now you're in the world of the wolves... And we welcome all you sheep... VRCC-#7196 VRCCDS-#0175 DTR PGR |
|
|
Joe Hummer
Member
Posts: 1645
VRCC #25677 VRCC Missouri State Representative
Arnold, MO
|
|
« Reply #7 on: January 09, 2012, 03:27:46 PM » |
|
Hey Bad, Had the same problem. When I got my bike, it had the bakers but not the fork lowers. I made my own lowers.  The lowers almost completely block the wind coming under the fairing / over the tank. The bakers will scoop air into me during the summer so I leave the lowers in place. Joe |
|
|
|
|
Logged
|
1999 Valkyrie Interstate
You pay for the whole bike, why not use it Jerry Motorman Palladino
|
|
|
|
3W-lonerider
|
|
« Reply #8 on: January 09, 2012, 03:27:57 PM » |
|
had the same problem when i took those little deflectors off to install the bakers..put a set of fork deflectors on and that eliminated most of the chest wind.. keep in mind..when you install the fork deflectors..you will have to angle them towards the front of the fender. OR the first time you turn the handle bars they will smack the pods.
|
|
|
|
|
Logged
|
|
|
|
Bad On 3
Member
Posts: 103
RIDIN THE BEAST ! !
CHICAGO IL. 60638
|
|
« Reply #9 on: January 09, 2012, 04:36:11 PM » |
|
Thanks guys your right i robbed peter to pay paul but they say a happy wifee is a happy me  the bakers stoped the wind from hitting her so i will try to fix my problem --joesvalk i love the wings you made how or what did you use to mount them Thanks again |
|
|
|
|
Logged
|
Ridin Down The Road Of Life With My Friends !! What a Ride !!
|
|
|
|
Flask
|
|
« Reply #10 on: January 09, 2012, 05:21:08 PM » |
|
The fork deflectors definitely took care of the air coming up on my chest. Fork Brackets - Memphis Shades # 9887 Deflectors - I made out of aluminum plate and had painted.    |
|
|
|
|
Logged
|
|
|
|
|
Karen
|
|
« Reply #11 on: January 09, 2012, 08:18:53 PM » |
|
Nice work!
|
|
|
|
|
Logged
|
|
|
|
GJS
Member
Posts: 424
Today is the tomorrow you worried about yesterday.
Vancouver Island, BC, Canada
|
|
« Reply #12 on: January 09, 2012, 10:10:07 PM » |
|
Yes! Very nice work.
I'll buy a set if your ever selling. (unpainted would be best)
Cheers,
Glenn
|
|
|
|
|
Logged
|
The tragedy of life is not that it ends so soon, but that we wait so long to begin it.
- W. M. Lewis
|
|
|
|
PhredValk
|
|
« Reply #13 on: January 09, 2012, 10:19:42 PM » |
|
Flask, what did you cut the plates with?
Fred.
|
|
|
|
|
Logged
|
Growing old is mandatory, growing up is optional.
VRCCDS0237
|
|
|
|
Flask
|
|
« Reply #14 on: January 10, 2012, 05:45:29 AM » |
|
Flask, what did you cut the plates with?
Fred.
Used 3/16" aluminum plate and cut with standard hand held jig saw. Filed and sanded edges. Kept playing with design to contour top side with fairing and also width size so when you turn handlebars to stop, they did not hit pods. You can play with adjustment on forks - be it height and angle to get clearances. |
|
|
|
|
Logged
|
|
|
|
|
Flask
|
|
« Reply #15 on: January 10, 2012, 05:51:23 AM » |
|
Yes! Very nice work.
I'll buy a set if your ever selling. (unpainted would be best)
Cheers,
Glenn
Have been meaning to cut out a few more sets - I guess down low on the list to be done. Keep putting a bug in my ear to get er done !!! |
|
|
|
|
Logged
|
|
|
|
John Schmidt
Member
Posts: 15260
a/k/a Stuffy. '99 I/S Valk Roadsmith Trike
De Pere, WI (Green Bay)
|
|
« Reply #16 on: January 10, 2012, 11:12:46 AM » |
|
Yes! Very nice work.
I'll buy a set if your ever selling. (unpainted would be best)
Cheers,
Glenn
Have been meaning to cut out a few more sets - I guess down low on the list to be done. Keep putting a bug in my ear to get er done !!! BUGGITY, BUGGITY, BUGGITY.........  Rick, I'll get up there one of these days, what I cobbled together now doesn't do the trick. |
|
|
|
|
Logged
|
|
|
|
|
Flask
|
|
« Reply #17 on: January 10, 2012, 04:20:07 PM » |
|
Yes! Very nice work.
I'll buy a set if your ever selling. (unpainted would be best)
Cheers,
Glenn
Have been meaning to cut out a few more sets - I guess down low on the list to be done. Keep putting a bug in my ear to get er done !!! BUGGITY, BUGGITY, BUGGITY......... Rick, I'll get up there one of these days, what I cobbled together now doesn't do the trick. Just give me some heads up John - Lets geter Done |
|
|
|
|
Logged
|
|
|
|
|
PhredValk
|
|
« Reply #18 on: January 10, 2012, 08:40:23 PM » |
|
Flask, any chance you could put up a template to save us all the experimentation? Or, if you make more, I know a few people who would pay a nice price for a set.
Even if you send them raw and I have to do the filing, sanding and paint.
Fred.
|
|
|
|
|
Logged
|
Growing old is mandatory, growing up is optional.
VRCCDS0237
|
|
|
GJS
Member
Posts: 424
Today is the tomorrow you worried about yesterday.
Vancouver Island, BC, Canada
|
|
« Reply #19 on: January 11, 2012, 09:49:52 AM » |
|
+1, Like Phred Said!
|
|
|
|
|
Logged
|
The tragedy of life is not that it ends so soon, but that we wait so long to begin it.
- W. M. Lewis
|
|
|
GOOSE
Member
Posts: 704
D.S. #: 1643
Southwest Virginia
|
|
« Reply #20 on: January 11, 2012, 02:18:39 PM » |
|
Flask....Those plates look GREAT....I think you could make it by just making/selling them.
|
|
|
|
|
Logged
|
|
|
|
|
Flask
|
|
« Reply #21 on: January 14, 2012, 04:23:41 AM » |
|
Calling - GJS I had E-mailed you thru the VRCC - have not heard back - Did not know if it went thru. I cut out some of those wind deflectors - If interested E-Mail me. Rick Flanders (Flask) tark4@bellsouth.net |
|
|
|
|
Logged
|
|
|
|
|
valknomad
|
|
« Reply #22 on: January 14, 2012, 08:28:43 PM » |
|
I'm currently working on a template/pattern to make a Lowers Mounting Bracket. I'll have it scanned and burned on a plasma torch/table. Most manufactured Lowers I see are more for show, and not a lot a wind deflection.
|
|
|
|
|
Logged
|
|
|
|
|
Flask
|
|
« Reply #23 on: January 15, 2012, 05:09:47 AM » |
|
I'm currently working on a template/pattern to make a Lowers Mounting Bracket. I'll have it scanned and burned on a plasma torch/table. Most manufactured Lowers I see are more for show, and not a lot a wind deflection.
This is exactly why I made the ones you see above. For the Interstate Fairing - It took care of the air coming up on my stomach / chest area. Also had to take care in that they did not hit the pods when fully turned. Looks like yours will be for Standard / Tourer. Post pics when you get them done. |
|
|
|
|
Logged
|
|
|
|
FloridaValkRyder
Member
Posts: 1677
If your offended , you need a history lesson!!
Apopka, Florida
|
|
« Reply #24 on: January 16, 2012, 10:04:04 PM » |
|
Yes! Very nice work.
I'll buy a set if your ever selling. (unpainted would be best)
Cheers,
Glenn
Have been meaning to cut out a few more sets - I guess down low on the list to be done. Keep putting a bug in my ear to get er done !!! BUGGITY, BUGGITY, BUGGITY......... Rick, I'll get up there one of these days, what I cobbled together now doesn't do the trick. Just give me some heads up John - Lets geter Done Let me know John, I would love to do that ride and meet Rick. Plus..having an I/S, I would love to buy a set of those deflectors!! |
|
|
|
« Last Edit: January 16, 2012, 10:05:43 PM by FloridaValkRyder »
|
Logged
|
I still miss her.
|
|
|
|
Farther
|
|
« Reply #25 on: January 18, 2012, 06:44:28 AM » |
|
--any input would be great --Thanks and Ride Safe !!!!!
Maybe you should be driving your cage instead of the bike. |
|
|
|
|
Logged
|
Thanks,
~Farther
|
|
|
|
Westsider
|
|
« Reply #26 on: January 18, 2012, 07:08:17 AM » |
|
--any input would be great --Thanks and Ride Safe !!!!!
Maybe you should be driving your cage instead of the bike. Imagine that , on a mc even!!!!!  jk jk |
|
|
|
|
Logged
|
we'll be there when we get there - Valkless,, on lookout....
|
|
|
|
