IS headlight kill switch options

Started by rekit, Mon 29, Apr 2019, 08:33:12

Previous topic - Next topic
Print
Go Down Pages1
User actions

rekit

Mon 29, Apr 2019, 08:33:12
I want to put a headlight kill switch on my 99 IS. Might save me one day if battery is low. Where is the best place to put one?  Would rather not cut wires if possible.
Bought a brand new Z1 in 74 and sold it later to get a "family car" DOH!! My brother had a Kaw H1 at the time as well. Oh well, good times! Lately Mean Streak, CBX, Nighthawk 750, Connie, KZ1000, Yamaha TTR 250, KTM 250

The emperor has no clothes

#1
Mon 29, Apr 2019, 08:50:28
If that day comes, it might be a lot easier to just pull the fuse.

Ramie

#2
Mon 29, Apr 2019, 11:59:30
Best way would be to put the headlight on a relay powered of the battery directly.  That would save your starter switch and allow you to put a switch on the trigger power to the relay.
"I am not a courageous person by nature. I have simply discovered that, at certain key moments in this life, you must find courage in yourself, in order to move forward and live. It is like a muscle and it must be exercised, first a little, and then more and more.  A deep breath and a leap."

MarkT

#3
Mon 29, Apr 2019, 12:08:13 Last Edit: Mon 29, Apr 2019, 13:33:09 by MarkT
I installed a sw that cuts the blue-wh wire which feeds into the hi-lo sw, and is used downstream to also trigger the relays for the spots and the relays for the headlight.  Just for the occasions when I need to power the engine but not waste power on the big lights.  Or if the battery is low, having alternator problems.  This happened when my alternator was failing per the volt readout as I was almost home from the Roanoke Inzane. Saved fixing the problem until after I was home.  Sw location doesn't help much on your IS install but might help another with a Std/Tour.  I wanted it to be reachable while riding so I can sw the lights off away from traffic but on when safety/visibility is needed. Look close below the turn signal bezel.


Vietnam-474 TFW Takhli 9-12/72 Linebckr II;307 SBW U-Tapao 05/73-4

The emperor has no clothes

#4
Mon 29, Apr 2019, 13:10:31
Quote from: Ramie on Mon 29, Apr 2019, 11:59:30
Best way would be to put the headlight on a relay powered of the battery directly.  That would save your starter switch and allow you to put a switch on the trigger power to the relay.
The interstates already have a relay saving the starter switch.

rekit

#5
Mon 29, Apr 2019, 14:54:17
Thanks all. Anyone got a link to a wiring diagram? Rattlebars didn't work.
Bought a brand new Z1 in 74 and sold it later to get a "family car" DOH!! My brother had a Kaw H1 at the time as well. Oh well, good times! Lately Mean Streak, CBX, Nighthawk 750, Connie, KZ1000, Yamaha TTR 250, KTM 250

Paladin528

#6
Wed 01, May 2019, 06:46:57
Rattlebars site is gone.  Did anyone save any of that information?

MarkT

#7
Wed 01, May 2019, 08:32:01 Last Edit: Wed 01, May 2019, 08:44:02 by MarkT

Vietnam-474 TFW Takhli 9-12/72 Linebckr II;307 SBW U-Tapao 05/73-4

rekit

#8
Sat 04, May 2019, 19:22:14
Thanks Mark T and all. The link works, and I have saved it. I'm not getting emails about new posts, I'l have to check what is up w/that.
Bought a brand new Z1 in 74 and sold it later to get a "family car" DOH!! My brother had a Kaw H1 at the time as well. Oh well, good times! Lately Mean Streak, CBX, Nighthawk 750, Connie, KZ1000, Yamaha TTR 250, KTM 250
